RC GA 41 SERIES is UV curable gloss ink with hard ink film and chemical resistance.

Polycarbonate, PVC stickers, rigid PVC, treated PET films, AS, ABS, acryl(injections).

• Excellent curing and adhesion.
• Stable on the screen and good reproducibility.
• High gloss and transparency.
• High gloss and transparency.
• Low skin irritation(P.I.I<2.0). Safe to handle.

COLORS

WHITE, OPAQUE WHITE, LEMON YELLOW, YELLOW, DEEP YELLOW, ORANGE, BRIGHT RED, RED, GERANIUM, PINK, VIOLET,

DEEP BLUE, BLUE, MARINE BLUE, GREEN, BLACK

CLEAR

1. 41-00 CLEAR
   Compatible with gold and silver powder. To adjust viscosity. For various over-coating, High-gloss and good levelling.
2. 41-00 TRANSPARENT CLEAR
   Good transparency. Non-silicone.
3. 41-00 MATT CLEAR
   For pseudo-etching effects and non-glare printing. High thixotropy. Good reproducibility of mesh pattern.
4. 41-00 TRANSPARENT MATT CLEAR
   For pseudo-etching effects and non-glare printing with transparency. High viscosity and transparency.
5. 41-00 HFT MATT CLEAR
   Flat and matt finish
6. 41-00 DP-1 CLEAR
   Coarse textured surface. Good scratch resistance.
7. 41-00 UF-1 CLEAR
   Finer version of DP-1.
8. 41-00 UB-1 MATT CLEAR
   Fine textured surface(high density)
9. 41-00 UB-2 MATT CLEAR
   Fine textured surface(low density)
10. 41-00 RL-A RELIEF CLEAR
    For relief print. Ink film is hard and suitable for thick substrate.
11. 41-00 RL-B RELIEF CLEAR
    For relief print. Ink film is relatively soft and suitable for thin substrate.
12. 41-00 RL-C CLEAR
    For braille points. Ink film is hard and suitable for thick substrate.
13. 41-00 RL-D CLEAR
    For braille points. Ink film is relatively soft and suitable for thin substrate.

1. Ink is supplied in ready-to-use condition. Stir well before use.
2. Add 41-00 REDUCER up to 10%, if necessary.
3. Standard curing conditions: (These conditions change depending on the substrate.)
   One metal halide lamp 120W/cm, Distance from focus : 10cm
   Conveyor speed : 10m/min (Integral light : approx. 250mJ/cm²)
4. Mesh : 300-350 meshes/inch, Thickness of sol : <10 microns

1. Skin irritation(P.I.I.) of each color is low(under 2.0). However, it is advised to avoid skin contact. In case of skin contact, please wash with soap and water immediately.
2. Store the ink in a cool and dark place. Stir occasionally to keep stability when the ink is stored for a long time.
3. Hard ink film is the characteristics of GA 41 SERIES. When flexible ink film is required, use RC PF 42 SERIES, RC VX 47 SERIES or RC M 47 SERIES
4. Please refer to MSDS before use.
5. Be sure to do trial print before commercial run to confirm that the product fits the purposes.

70-80m²/kg
